Specs
Details
-
       Platform
-
       Model NameSynapse Carbon 4
-
       Model CodeC12075U
Frameset
-
       FrameSynapse Carbon, Proportional Response construction, integrated cable routing, downtube Stashport, 12x142 thru-axle, UDH, BSA 68mm threaded BB, flat mount disc, integrated seat binder, SmartSense Gen 2.0 compatible, fender mounts
-
       ForkSynapse Carbon, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/5" Delta steerer, 55mm offset, fender mounts
-
       HeadsetIntegrated, 1-1/8" - 1-1/2"
Drivetrain
-
       Rear DerailleurShimano 105 Di2 7150
-
       Front DerailleurShimano 105 Di2 7150, braze-on
-
       ShiftersShimano 105 Di2 R7170, wireless, 12-speed
-
       ChainShimano 105 7100, 12-speed
-
       CrankShimano 105 7100, BSA, 50/34
-
       Rear CogsShimano 105 7100, 11-34, 12-speed
-
       Bottom BracketShimano BSA 68
Brakes
-
       BrakesShimano 105 7170 hydraulic disc, 160/160mm RT70 rotors
-
       Brake LeversShimano 105 Di2 7170 hydraulic disc
Wheels
-
       RimsDT Swiss R470 db, 28h
-
       SpokesStainless Steel, 14g
-
       Tire Size32
-
       Wheel Size700c
-
       Hubs(F) Shimano RS470, 12x100mm centerlock / (R) Shimano RS470, 12x142mm centerlock
-
       TiresVittoria Rubino Pro IV, 700x32c
Components
-
       HandlebarVision Trimax Aero Alloy
-
       StemCannondale C1 Conceal, Alloy, 31.8, -6°
-
       GripsCannondale Bar Tape, 3.5mm
-
       SaddleFizik Vento Argo X5, 140mm
-
       SeatpostCannondale C1 Aero 27 Carbon, SmartSense compatible, 330mm length, 0mm offset (44-48cm), 15mm offset (51-61cm)
Connectivity
-
       Wheel SensorCannondale Wheel Sensor
Extra
-
       Extra 1Large StashBag downtube storage bag
Please note that, based on component availability and other factors, specifications are subject to change without notice.
